FULL DESCRIPTION of Item 186199

in Rotary Vane Pumps
Deal directly with Owner:  Capovani Brothers Inc. of Scotia, New York

Item ID: 186199

Offered1 Offered at Best Price


OERLIKON LEYBOLD ROTARY VANE VACUUM PUMP 247 CFM

Two-Stage Rotary Vane Pump
OERLIKON LEYBOLD ROTARY VANE VACUUM PUMP 247 CFM
  Click to see additional image(s)... other images

Location: Scotia, NY
Unit Price Unstated
Number of Units 1
Manufacturer Oerlikon Leybold
Model Trivac D8B
Pumping Speed 247.0  CFM  (6,979.6 l/m)
Ultimate Pressure  1.50E-3(En)  torr  (2.00E-3 mbar)
Inlet Flange KF     16.0  mm  (0.630 in)
Exhaust Flange KF     16.0  mm  (0.630 in)
Two-Stage YES
Ultimate Total Pressure with Gas Ballast  3.75E-3(En)  torr  (5.00E-3 mbar)
Ultimate Total Pressure without Gas Ballast  1.50E-3(En)  torr  (2.00E-3 mbar)
Direct Drive Yes
Motor Horsepower .885  HP
Oil Type Hydrocarbon
Oil Capacity Minimum: 0.30  L  (0.32 qt, 0.07 Br gal)     Maximum: 0.90  L  (0.95 qt, 0.20 Br gal)
Other Information Part No: 140082
Motor Type: E8CD4B2-8
Power Requirements: 100-115 V /5.6 A, 210-230 V / 2.8 A, 50/60 Hz, 1 Phase

Extended Description  Details at Oerlikon Leybold D8B Rotary Vane Vacuum Pump.pdf
Condition New-Never Used
CE Marked YES
Exterior Dimensions
  Width 6.378  in  (16.2 cm)
  Depth 18.976  in  (48.2 cm)
  Height 10.433  in  (26.5 cm)
Weight 47  lb  (21 kg)
