Item ID: 195478

**1 Offered at $ 6,900.00**

SUN ELECTRONICS SYSTEMS TEMPERATURE CHAMBER -73C TO 315C, 6.16 CU.FT

Temperature Chamber
Liquid CO2, High Pressure 850 PSI

... other images

Location: Scotia, New York

Unit Price	$ 6,900.00
Number of Units	1
Manufacturer	Sun Elect. Sys
Model	EC16
Minimum Temperature	-73 ºC (-99 ºF, 200.00 ºK)
Maximum Temperature	315 ºC (599 ºF, 588 ºK)
Temperature Control
Control Stability	± 0.500 ºC
Heat/Cool Controls
Control Type	Programmable
Overtemperature Protection	YES
Interface	IEEE 488-GPIB
Capacity/Volume Box	6.16 cu ft (0.17 cu m)
Chamber Characteristics
Chamber Construction	Stainless Steel
Number and Size of Access Ports	2-3" Left side
Chamber Size
Width	22.00 in (55.88 cm)
Depth	22.00 in (55.88 cm)
Height	22.00 in (55.88 cm)
External Cooling	Air Cooled
Accessories	Remote Control: RS232 / RS422 / IEEE-488 bus
Other Information	Chamber configured for LCO2 @ 850 PSI Features: Heat/cool enable and disable switches Battery backed memory Setup menus for probe CAL. Time of day clock Remote interrupt operation and default conditions for alarms and interfaces IEEE/RS232/RS422/IO Port Controller: Programmable controller Model TC10 100 plus segments (Temps. and Time) Stability per month: ±0.2°C Resolution: 0.02°C Gas coolant usage @ 0°C 2 lbs hour(LCO2) Hot/cold rate of exchange: 0.5°C/sec Air flow: 60 CFM Digital readout CE label Power: 6000W at 220V, 50/60 Hz, Single Phase
Extended Description	Details at Sun Electronics EC16.PDF
Power Requirements	220 V 50/60 Hz 1 Phase
CE Marked	YES
Year of Manufacture	2005
Exterior Dimensions
Width	32.000 in (81.3 cm)
Depth	36.000 in (91.4 cm)
Height	29.500 in (74.9 cm)
Weight	139 lb (63 kg)
