Deal directly with Owner:  Capovani Brothers Inc. of Scotia, New York
Item ID: 172335

Offered 4 Offered at $ 1,999.00 (each)


High Voltage Power Supply Positive or Negative Polarity

Location: Scotia, New York
Unit Price $ 1,999.00 (each)
Number of Units 4
Manufacturer Glassman
Model + PS/FC05P24 or - PS/FC05N24
Maximum Output Voltage 5.0 kV
Maximum Output Current 24.0 mA
Bipolar No
Panel Meters Digital
Ripple <0.02% RMS of rated voltage +300mV at full load
Regulation Better than 0.1%
Interface I/O Port
External Cooling Air Cooled
Other Information

Positive or Negative Polarity, request when ordering (not user configurable)
Can be configured for 230VAC input, request when ordering (not user configurable)
SHV output connector, high voltage cable is NOT included
RS232 option is NOT included

We will not honor our 90 day warranty if this power supply will be used for arc or spark gap applications


Extended Description  Details at FC_SeriesSpecs.pdf
Power Requirements 115 V     48-440 Hz     1¬†Phase
Condition Excellent
Exterior Dimensions
  Width 19.000  in  (48.3 cm)
  Depth 20.000  in  (50.8 cm)
  Height 1.720  in  (4.4 cm)
Weight 12  lb  (5 kg)
