Unit Price |
Unstated |
Number of Units |
1 |
Manufacturer | Despatch |
Model | LND 2-11-3 |
Maximum Temperature | 343 ºC (649 ºF, 616 ºK) |
Heat/Cool Controls |  |
Control Type | Programmable |
Overtemperature Protection | YES |
Controller Manufacturer/Model | Despatch Protocol |
Capacity/Volume Box | 11.40 cu ft (0.32 cu m) |
Chamber Size |  |
Width | 38.00 in (96.52 cm) |
Depth | 20.00 in (50.80 cm) |
Height | 26.00 in (66.04 cm) |
Chamber Characteristics |  |
Chamber Construction | Stainless Steel |
Maximum Number of Shelves | 6 |
Number of Shelves Provided | 0 |
External Cooling | Water Cooled |
Other Information | Uniformity: ±1.2% Control sensitivity: ±0.25% Max N2 inlet pressure: 40 psig Heater: 9 kW
|
Power Requirements | 208 V
29.8 A
60 Hz
3 Phase
|
Exterior Dimensions |  |
Width | 53.500 in (135.9 cm) |
Depth | 40.500 in (102.9 cm) |
Height | 63.000 in (160.0 cm) |
Weight | 752 lb (341 kg) |
