Unit Price |
$ 5,250.00 |
Number of Units |
1 |
Manufacturer | Leitz |
Model | Ergolux |
Microscope Configuration | Brightfield & Darkfield |
Illumination Type | Reflected & Transmitted Light |
Binocular Angle | Variable |
Eyepieces |  |
Model | Periplan |
Magnification | 12 X |
Field Number | 20 mm |
Focusing | YES |
Magnification Changer | 1, 1.25, 1.6, 2 |
Motorized Nosepiece | YES |
Multiple Objectives Models |
- Plan L25x/0.40
- Plan L50x/0.60 with interference contrast device R
- PlanL125x/0.80
- Fluotar 5x/0.09 DF
- HL 50x/0.65 DF
|
Polarizer | YES |
Analyzer | YES |
Condenser | YES |
Illumination Power | Volts: 6
Watts: 20
|
Power Supply Included | YES |
Stage Type | Coaxial X-Y |
Stage Area | Length: 178 mm (7.008 in)
Width: 298.0 mm (11.732 in)
|
X-Y-Z Stage Travel | X: 102 mm (4.016 in)
Y : 102 mm (4.016 in)
|
Accessories |
- Analyzer part#- 513575
- Polarizer part#- 553391
- Lambda Plate part#- 553392
- V Diapragm Slide DF
|
Other Information | Modulopak vertical illuminator has 0.08x tube lens Glass plate for stage will be provided
110/120-130/220-230/240-250 volt |
Power Requirements |
50/60 Hz
1 Phase
|
Exterior Dimensions |  |
Width | 10.000 in (25.4 cm) |
Depth | 25.000 in (63.5 cm) |
Height | 27.000 in (68.6 cm) |
Weight | 44 lb (20 kg) |
